AJAX TCP-IPGSM Alarm Hub2 (Supports PIR With Video Verification)

Classification :  Intelligent security system control panel supporting ethernet and two SIM cards
Maximum number of connected devices : 100
Maximum number of the groups : 9
Maximum number of the Hub users : 50
Maximum number of logical rooms : 50
Scenarios  : Up to 32 (Reactions by arming and disarming are not included in the overall limit of the hub’s scenarios)
Power supply : 110 – 240 V AC, 50 / 60 Hz
Central Monitoring Station communication protocols :  Contact ID, SIA
Built-in rechargeable battery :  Li-Ion 2 Ah (up to 16 hours of battery life when Ethernet connection is disabled)
Energy consumption from the grid :  10 Wh
Tamper proof :  Available, tamper
Operating frequency band :  868.0 – 868.6 MHz or 868.7 – 869.2 MHz, depending on the sales region
RF output power :  8.20 dBm / 6.60 mW (limit 25 mW)
Radio signal modulation :  GFSK
Radio signal range :  Up to 2,000 m (any obstacles absence)
Communication channels  : 2 SIM cards (GSM 850/900/1800/1900 MHz GPRS) / Ethernet
Operating temperature range :  From -10°? to +40°?
Operating humidity :  Up to 75%
Dimensions :  163 × 163 × 36 mm
Weight :  362 g
