AJAX TCP-IPGSM Alarm Hub2 LTE

Classification : Security system control panel
Colour : White
Installation method : Indoors
Hub 2 (4G) communication channels  2 SIM cards / 2G : (GSM900/DCS1800 (B3/B8)) / 3G : (WCDMA 850/900/2100 (B1/B5/B8)) / LTE : (FDD B1/B3/B5/B7/B8/B20/B28)
Ethernet
Communication protocols  : Encrypted two-way radio protocols:
Jeweller : for transmitting events and alarms
Wings : for transmitting photos
Radio communication range  :Up to 2000 m without obstacles
Radio frequency band : 866.0 – 866.5 MHz(depending on the sales region)
Radio signal modulation : GFSK
Maximum effective radiated power : (ERP) ≤ 25 mW
Polling interval  :12–300 s (set by administrator in the app)
Time for alarm delivery from detector to hub : 0.15 s
Time for photo delivery from detector to hub  : up to 9 s at default settings
Number of connected devices : up to 100 including range extenders and sirens
Number of connected ReX : up to 5
Number of connected sirens : up to 10
Number of security groups : up to 9
Number of users : up to 50
Video surveillance : up to 25 cameras or DVRs
Number of rooms : up to 50
Number of scenarios : up to 32
Central Monitoring Station communication protocols : SurGard (Contact ID) / SIA(DC-09) / Other proprietary protocols
Power supply :  110–240 V with a pre-installed power supply unit / 12 V with an alternative power supply unit 12V PSU / 6 V with an alternative power supply unit 6V PSU
Backup battery Li-Ion 2 Ah : (up to 16 h of battery life with Ethernet disabled)
Energy consumption from the grid : 10 W
Anti-sabotage protection : Tamper + / Radio frequency hopping + / Fraud protection + / Lid
Operating temperature range :  From -10°C to +40°C
Operating humidity :  Up to 75%
Dimensions : 163 × 163 × 36 mm
Weight : 362 g
